Constructed with high-strength steel and wear-resistant tires (pneumatic for outdoor use), it delivers exceptional durability on various terrains. Easy maintenance minimizes downtime, and customizable options (fork length, attachments) enhance versatility. A cost-effective choice for boosting material handling efficiency across industries.
| Technical Performance Parameters | |||||
| General | Model | CPCD | |||
| Power Type | Diesel | ||||
| Load Capacity | kg | 3000 | 3500 | ||
| Load Center | mm | 500 | |||
| D imension | Lift Height | mm | 3000 | 3000 | |
| Free Lift Height | mm | 105 | 110 | ||
| Fork Size | mm | 1220×125×45 | 1220×125 ×50 | ||
| Mast Tilt Angle | deg | 6 °/12 ° | |||
| Front Overhang | mm | 487 | 492 | ||
| Rear Overhang | mm | 562 | |||
|
Overall Dimension |
Length to face of fork | mm | 4019 | 4024 | |
| Overall Width | mm | 1225 | |||
| Mast Lowered Height | mm | 2075 | |||
| Mast Extended Height | mm | 4230 | |||
| Overhead Guard Height | mm | 2100 | |||
| Turning Radius(outsiade) | mm | 2555 | |||
| Performance |
Full load/No load |
Travel Speed | km/h | 18/19 | |
| Lift Speed | mm/s | 450/470 | 410/420 | ||
| Max.Gradeability | % | 15/20 | |||
| Service Weight | kg | 4270 | 4600 | ||
| Chassis | Tyre | Front | 28×9-15-12PR | ||
| Rear | 6.50-10-10PR | ||||
| Tread | Front | mm | 1000 | ||
| Rear | mm | 970 | |||
| Wheelbase | mm | 1750 | |||
| Minimum ground clearance | Mast | mm | 125 | ||
| Dr ive units & control | Battery | V/AH | 12/80 | ||
| Engine | Model | Quanchai QC490GP | |||
| Rated output/r.p.m | kw/r.p.m | 37/2650 | |||
| Rated torque/r.p.m | Nm/r.p.m | 160/1980 | |||
| NO.of Cylinder | 4 | ||||
| Bore×Stroke | mm | 90×105 | |||
| Displacement | L | 2.67 | |||
|
Transmissions |
Type | Electronic shift | |||
| Stage ( FWD/RVS) | 1-1 | ||||
